Switchboard

A lightweight reverse proxy and API gateway for .NET

</div>

---

Overview

Switchboard is a production-ready reverse proxy and API gateway that combines enterprise-grade features with .NET simplicity. Route traffic to multiple backends, automatically handle failures, enforce rate limits, and implement custom authentication—all with minimal configuration.

🚀 Flexible Deployment: Embed directly into your .NET application as a library or run as a standalone server.

---

Table of Contents

• What is Switchboard?
• What's New in v5.0.0
• Key Features
• Who is it for?
• When to Use Switchboard
• What It Does
• What It Doesn't Do
• Quick Start
• Installation
• Usage Examples
  • Integrated (Library)
  • Standalone Server
  • Docker
• Configuration
• Advanced Features
  • URL Rewriting
  • Authentication Context Forwarding
  • Server-Sent Events
  • Chunked Transfer Encoding
  • OpenAPI Documentation
• Management API & Dashboard
  • Enabling the Management API
  • Running the Dashboard
  • Database Configuration
  • Request History
• Observability
• Support
• Contributing
• License
• Version History

---

What is Switchboard?

Switchboard is a lightweight application proxy that combines reverse proxy and API gateway functionality for .NET applications. It acts as an intelligent intermediary between your clients and backend services, providing:

• Traffic routing to multiple origin servers
• Automatic health checking and failover
• Load balancing across healthy backends
• Rate limiting to protect your services
• Authentication and authorization via flexible callbacks
• URL rewriting for API versioning
• Protocol support for HTTP, chunked transfer encoding, and server-sent events (SSE)

Built on .NET 8.0 and .NET 10.0, Switchboard is designed for developers who need a simple, embeddable gateway without the complexity of heavyweight solutions.

<details> <summary><strong>📸 Screenshots — a tour of the management dashboard</strong></summary>

<br>

Request history & activity — the operator view, with a live request-activity chart (success vs. failure over time), retained / failures / success-rate / average-duration KPIs, filtering, and a paginated history table.

Request details — drill into any proxied request to see status, timing, request/response sizes, identifiers, and captured headers, then replay it in the API Explorer.

Origin servers — the backend targets Switchboard proxies to, with hostname, port, TLS, health status, and concurrency limits; click any row for the full origin configuration.

API endpoints — route groups showing each endpoint's URL routes, per-route HTTP methods, and load-balancing mode, with an inline route editor.

API Explorer — an OpenAPI-driven console to browse and try the management API against the running server, complete with generated cURL and fetch() snippets.

</details>

---

What's New in v5.0.0

Current version: v5.0.0. See the change log for the complete history.

Highlights in this release:

• Observability with OpenTelemetry – Metrics and traces export over OTLP: request rate/latency/body sizes, per-origin load/health/ejections, load-balancer selections, and retries/failovers, plus one span per proxied request with traceparent propagated downstream. docker compose up brings up a turnkey Prometheus + Tempo + Loki + Grafana stack (Grafana on :3001, pre-provisioned dashboard). See the Observability section.
• Intelligent routing and load balancing – Four new load-balancing modes (least-connections, power-of-two-choices, weighted, and latency-based) plus passive health checks with outlier ejection, automatic retries/failover, sticky sessions, slow start, and per-endpoint weighted canary with header routing. See LOAD_BALANCING.md for the full picture.
• Live origin health monitoring – Per-origin uptime, a rolling check-history histogram, and last-error surfaced through GET /origins/health and the dashboard.
• Live configuration – Origins, endpoints, routes, and rewrites created through the dashboard or management API now take effect on the running proxy automatically, no restart required.
• Reworked management dashboard – Grouped navigation, an operator overview with KPI cards and a request-activity chart, a request-history inspector, a form-based settings editor that flags restart-required changes, an OpenAPI-driven API Explorer, and a first-run setup wizard.
• Contextual help everywhere – Every form control in the dashboard has a hover tooltip explaining what the field does, its effect, and valid values.
• Expanded internationalization – The dashboard ships in nine languages: English, Spanish, German, French, Portuguese, Mandarin, Cantonese, Japanese, and Farsi (right-to-left).
• New management API endpoints – GET /history/timeseries, GET/PUT /settings, POST /config/validate, and POST /system/restart.
• Writable default admin – The out-of-box admin credential can create, update, and delete resources; permission failures return 403 (not 401), so a read-only user is no longer logged out when attempting a write.
• Fixes – Origin/endpoint edit and delete by GUID, setup-wizard SSL port defaulting (443/80), and whole-number activity-chart axes.

---

Key Features

• ✅ Intelligent Load Balancing – Round-robin, random, least-connections, power-of-two-choices, weighted, and latency-based (EWMA), with priority tiers, sticky sessions, slow start, passive ejection, retries/failover, and weighted canary (details)
• ✅ Observability – OpenTelemetry metrics + traces over OTLP, with a bundled Prometheus/Tempo/Loki/Grafana stack (details)
• ✅ Automatic Health Checks – Continuous monitoring with configurable thresholds
• ✅ Rate Limiting – Per-origin concurrent request limits and throttling
• ✅ Custom Authentication – Callback-based auth/authz with context forwarding
• ✅ URL Rewriting – Transform URLs before proxying to backends
• ✅ Protocol Support – HTTP/1.1, chunked transfer encoding, server-sent events
• ✅ Smart Routing – Parameterized URLs with wildcard matching (/users/{id})
• ✅ Header Management – Automatic proxy headers and configurable blocking
• ✅ Logging – Built-in syslog integration with multiple severity levels
• ✅ Docker Ready – Server and Dashboard available on Docker Hub (switchboard, switchboard-ui)
• ✅ Embeddable – Integrate directly into your application via NuGet
• ✅ OpenAPI Support – Auto-generate OpenAPI 3.0.3 docs with Swagger UI
• ✅ Management API – RESTful API for runtime configuration changes
• ✅ Web Dashboard – React-based UI for configuration and monitoring
• ✅ Database Backend – Store config in SQLite, MySQL, PostgreSQL, or SQL Server
• ✅ Request History – Track and analyze requests with searchable history

---

Who is it for?

Switchboard is designed for:

• Backend Developers building microservices architectures
• DevOps Engineers needing lightweight reverse proxy solutions
• API Platform Teams implementing centralized gateways
• .NET Developers who want embeddable proxy functionality
• System Architects designing high-availability systems
• Startups seeking simple, cost-effective infrastructure

---

When to Use Switchboard

Perfect for:

• Routing requests to multiple backend microservices
• Load balancing across identical service instances
• Centralizing authentication and authorization
• Implementing API versioning with URL rewrites
• Protecting backends from overload with rate limiting
• Building high-availability systems with automatic failover
• Proxying server-sent events or chunked responses
• Embedding a gateway directly into your .NET application

Not ideal for:

• Simple single-backend scenarios (use a direct connection)
• WebSocket proxying (use dedicated WebSocket gateways)
• Advanced routing rules (use full-featured API gateways like Kong, Tyk, or NGINX)
• Layer 4 load balancing (use HAProxy or cloud load balancers)

---

What It Does

Switchboard provides:

1. Request Routing – Match incoming requests to API endpoints using parameterized URLs
2. Load Balancing – Distribute traffic across origin servers with round-robin, random, least-connections, power-of-two-choices, weighted, or latency-based selection, plus priority tiers, sticky sessions, and weighted canary (see LOAD_BALANCING.md)
3. Health Monitoring – Automatically detect and route around unhealthy backends
4. Rate Limiting – Enforce concurrent request limits per origin server
5. Authentication – Invoke custom callbacks for auth/authz decisions
6. Authorization Context – Forward auth metadata to origin servers via headers
7. URL Transformation – Rewrite URLs before forwarding to backends
8. Error Handling – Return structured JSON error responses
9. Protocol Handling – Support chunked transfer encoding and server-sent events
10. Logging – Comprehensive request/response logging with syslog integration

---

What It Doesn't Do

Switchboard is intentionally lightweight and does not include:

• ❌ WebSocket proxying
• ❌ Advanced traffic shaping or QoS
• ❌ Built-in caching (use Redis or CDN)
• ❌ Request transformation/mutation (header rewriting beyond proxy headers)
• ❌ OAuth/JWT validation (implement via callbacks)
• ❌ GraphQL federation
• ❌ Service mesh features (circuit breakers, retries, distributed tracing) For these features, consider integrating Switchboard with specialized tools or using enterprise API gateways.

---

Quick Start

1. Install via NuGet (Integrated)

dotnet add package SwitchboardApplicationProxy

2. Run as Standalone Server

# Clone the repository
git clone https://github.com/jchristn/switchboard.git
cd switchboard/src

# Build the solution
dotnet build

# Run the server
cd Switchboard.Server/bin/Debug/net8.0
dotnet Switchboard.Server.dll

3. Run with Docker

docker pull jchristn77/switchboard
docker run -p 8000:8000 -v $(pwd)/sb.json:/app/sb.json jchristn77/switchboard

Visit http://localhost:8000/ to confirm Switchboard is running!

---

Installation

NuGet Package

Install the SwitchboardApplicationProxy package from NuGet:

dotnet add package SwitchboardApplicationProxy

Or via Package Manager Console:

Install-Package SwitchboardApplicationProxy

Docker Images

Pull from Docker Hub:

# Switchboard Server
docker pull jchristn77/switchboard:v5.0.0

# Switchboard Dashboard (Web UI)
docker pull jchristn77/switchboard-ui:v5.0.0

Docker images:

• Server: jchristn77/switchboard
• Dashboard: jchristn77/switchboard-ui

Build from Source

git clone https://github.com/jchristn/switchboard.git
cd switchboard/src
dotnet build

---

Usage Examples

Integrated (Library)

Embed Switchboard directly into your .NET application:

using Switchboard.Core;

// Initialize settings
SwitchboardSettings settings = new SwitchboardSettings();

// Add API endpoint with parameterized URLs
settings.Endpoints.Add(new ApiEndpoint
{
    Identifier = "user-api",
    Name = "User Management API",
    LoadBalancing = LoadBalancingMode.RoundRobin,

    // Public routes (no authentication)
    Unauthenticated = new ApiEndpointGroup
    {
        ParameterizedUrls = new Dictionary<string, List<string>>
        {
            { "GET", new List<string> { "/health", "/status" } }
        }
    },

    // Protected routes (require authentication)
    Authenticated = new ApiEndpointGroup
    {
        ParameterizedUrls = new Dictionary<string, List<string>>
        {
            { "GET", new List<string> { "/users", "/users/{userId}" } },
            { "POST", new List<string> { "/users" } },
            { "PUT", new List<string> { "/users/{userId}" } },
            { "DELETE", new List<string> { "/users/{userId}" } }
        }
    },

    // URL rewriting (e.g., API versioning)
    RewriteUrls = new Dictionary<string, Dictionary<string, string>>
    {
        {
            "GET", new Dictionary<string, string>
            {
                { "/users/{userId}", "/api/v2/users/{userId}" }
            }
        }
    },

    // Associate with origin servers
    OriginServers = new List<string> { "backend-1", "backend-2" }
});

// Add origin servers
settings.Origins.Add(new OriginServer
{
    Identifier = "backend-1",
    Name = "Backend Server 1",
    Hostname = "api1.example.com",
    Port = 443,
    Ssl = true,
    HealthCheckUrl = "/health",
    MaxParallelRequests = 20,
    RateLimitRequestsThreshold = 50
});

settings.Origins.Add(new OriginServer
{
    Identifier = "backend-2",
    Name = "Backend Server 2",
    Hostname = "api2.example.com",
    Port = 443,
    Ssl = true,
    HealthCheckUrl = "/health",
    MaxParallelRequests = 20,
    RateLimitRequestsThreshold = 50
});

// Start Switchboard
using (SwitchboardDaemon sb = new SwitchboardDaemon(settings))
{
    // Define authentication callback
    sb.Callbacks.AuthenticateAndAuthorize = async (ctx) =>
    {
        // Custom authentication logic (e.g., JWT validation)
        string authHeader = ctx.Request.Headers.Get("Authorization");

        if (string.IsNullOrEmpty(authHeader))
        {
            return new AuthContext
            {
                Authentication = new AuthenticationContext { Result = AuthenticationResultEnum.NotFound },
                Authorization = new AuthorizationContext { Result = AuthorizationResultEnum.Denied }
            };
        }

        // Validate token (example)
        bool isValid = ValidateToken(authHeader);

        return new AuthContext
        {
            Authentication = new AuthenticationContext
            {
                Result = isValid ? AuthenticationResultEnum.Success : AuthenticationResultEnum.InvalidCredentials,
                Metadata = new { UserId = "12345" }
            },
            Authorization = new AuthorizationContext
            {
                Result = isValid ? AuthorizationResultEnum.Success : AuthorizationResultEnum.Denied,
                Metadata = new { Role = "Admin" }
            }
        };
    };

    Console.WriteLine("Switchboard is running on http://localhost:8000");
    Console.ReadLine();
}

Standalone Server

Run Switchboard as an independent server using a configuration file:

1. Create sb.json configuration:

{
  "Logging": {
    "SyslogServerIp": null,
    "SyslogServerPort": 514,
    "MinimumSeverity": "Info",
    "LogRequests": true,
    "LogResponses": false,
    "ConsoleLogging": true
  },
  "Endpoints": [
    {
      "Identifier": "my-api",
      "Name": "My API",
      "LoadBalancing": "RoundRobin",
      "Unauthenticated": {
        "ParameterizedUrls": {
          "GET": ["/health", "/status"]
        }
      },
      "Authenticated": {
        "ParameterizedUrls": {
          "GET": ["/users", "/users/{id}"],
          "POST": ["/users"],
          "PUT": ["/users/{id}"],
          "DELETE": ["/users/{id}"]
        }
      },
      "OriginServers": ["backend-1", "backend-2"]
    }
  ],
  "Origins": [
    {
      "Identifier": "backend-1",
      "Name": "Backend 1",
      "Hostname": "localhost",
      "Port": 8001,
      "Ssl": false,
      "HealthCheckIntervalMs": 10000,
      "HealthyThreshold": 2,
      "UnhealthyThreshold": 2,
      "MaxParallelRequests": 10,
      "RateLimitRequestsThreshold": 30
    },
    {
      "Identifier": "backend-2",
      "Name": "Backend 2",
      "Hostname": "localhost",
      "Port": 8002,
      "Ssl": false,
      "HealthCheckIntervalMs": 10000,
      "HealthyThreshold": 2,
      "UnhealthyThreshold": 2,
      "MaxParallelRequests": 10,
      "RateLimitRequestsThreshold": 30
    }
  ],
  "Webserver": {
    "Hostname": "localhost",
    "Port": 8000
  }
}

2. Start the server:

dotnet Switchboard.Server.dll

            _ _      _    _                      _
  ____ __ _(_) |_ __| |_ | |__  ___  __ _ _ _ __| |
 (_-< V  V / |  _/ _| ' \| '_ \/ _ \/ _` | '_/ _` |
 /__/\_/\_/|_|\__\__|_||_|_.__/\___/\__,_|_| \__,_|

Switchboard Server v4.1.x

Loading from settings file ./sb.json
[INFO] Webserver started on http://localhost:8000
[INFO] Switchboard Server started

3. Test the endpoint:

curl http://localhost:8000/health

Docker

Switchboard provides Docker images and compose files for running both the server and web dashboard.

Quick Start with Docker Compose

The easiest way to run Switchboard with the dashboard is using the provided compose files:

cd Docker

# Start with SQLite (default, recommended for getting started)
docker compose -f compose.sqlite.yaml up -d

# Or use the default compose file
docker compose up -d

This starts every service in the stack. Default URLs and credentials:

Service	URL	Credentials
Switchboard Server (proxy + management API)	http://localhost:8000	Admin bearer token sbadmin (management API under /_sb/v1.0/)
Web Dashboard	http://localhost:3000	Sign in with the server URL and admin token sbadmin
Grafana	http://localhost:3001	No login — anonymous Admin access (if you disable it, Grafana defaults to admin / admin)
Prometheus	http://localhost:9090	None
OpenTelemetry Collector	OTLP :4317 (gRPC) / :4318 (HTTP), Prometheus exporter :8889	None (no UI)
Tempo (traces)	internal only — view via Grafana	None
Loki (logs)	internal only — view via Grafana	None

Change the admin token before exposing Switchboard beyond localhost: set Management.AdminToken in sb.json (or via Settings in the dashboard). In Grafana, Dashboards → Switchboard Overview is pre-provisioned; panels fill once traffic flows through the proxy. See the Observability section for details.

The database-specific compose files additionally start their database container with the credentials defined in that file (for example MySQL: user switchboard / password switchboard123).

Stop the services:

docker compose down
# or
./compose-down.sh  # Linux/Mac
compose-down.bat   # Windows

Database-Specific Compose Files

Choose a compose file based on your preferred database:

File	Database	Usage
compose.sqlite.yaml	SQLite	docker compose -f compose.sqlite.yaml up -d
compose.mysql.yaml	MySQL 8.0	docker compose -f compose.mysql.yaml up -d
compose.postgres.yaml	PostgreSQL	docker compose -f compose.postgres.yaml up -d
compose.sqlserver.yaml	SQL Server	docker compose -f compose.sqlserver.yaml up -d

Each compose file includes:

• The database service (except SQLite which uses a file)
• Switchboard server with appropriate configuration
• Web dashboard
• The observability stack (OpenTelemetry Collector, Prometheus, Tempo, Loki, and Grafana) — same URLs and credentials as the table above

Configuration

Each compose file uses a corresponding configuration file:

Compose File	Config File	Description
compose.yaml	sb.json	Basic config without database
compose.sqlite.yaml	sb.sqlite.json	SQLite with Management API enabled
compose.mysql.yaml	sb.mysql.json	MySQL connection settings
compose.postgres.yaml	sb.postgres.json	PostgreSQL connection settings
compose.sqlserver.yaml	sb.sqlserver.json	SQL Server connection settings

Example sb.sqlite.json (recommended starting point):

{
  "Database": {
    "Enable": true,
    "Type": "Sqlite",
    "Filename": "./data/switchboard.db"
  },
  "Management": {
    "Enable": true,
    "BasePath": "/_sb/v1.0/",
    "AdminToken": "sbadmin",
    "RequireAuthentication": true
  },
  "RequestHistory": {
    "Enable": true,
    "RetentionDays": 7
  },
  "Webserver": {
    "Hostname": "*",
    "Port": 8000
  }
}

Connecting to the Dashboard

1. Open http://localhost:3000 in your browser
2. Enter the server URL: http://localhost:8000
3. Enter the admin token from your config (default: sbadmin)
4. Click Connect

Volume Mounts

The compose files mount these directories:

Mount	Purpose
./sb.*.json:/app/sb.json	Server configuration
./logs/:/app/logs/	Log files
./data/:/app/data/	SQLite database and data files

Manual Docker Run (Server Only)

To run just the Switchboard server without compose:

docker run -d \
  --name switchboard \
  -p 8000:8000 \
  -v $(pwd)/sb.json:/app/sb.json \
  -v $(pwd)/logs:/app/logs \
  -v $(pwd)/data:/app/data \
  jchristn77/switchboard:v5.0.0

Building the Dashboard Image

The dashboard is built from source using a multi-stage Dockerfile:

# From the repository root
docker build -t jchristn77/switchboard-ui -f Docker/dashboard/Dockerfile .

See docs/DASHBOARD-GUIDE.md for dashboard usage details.

---

Configuration

Default Behavior

By default, Switchboard:

• Listens on http://localhost:8000/
• Returns a default homepage at / (GET/HEAD requests)
• Requires explicit API endpoint and origin server configuration

Health Check Defaults

If not explicitly configured:

• Method: GET /
• Interval: Every 5 seconds (HealthCheckIntervalMs)
• Unhealthy Threshold: 2 consecutive failures (UnhealthyThreshold)
• Healthy Threshold: 2 consecutive successes (HealthyThreshold)

Rate Limiting Defaults

If not explicitly configured:

• Max Parallel Requests: 10 per origin (MaxParallelRequests)
• Rate Limit Threshold: 30 total requests (active + pending) per origin (RateLimitRequestsThreshold)

Configuration File Options

For standalone deployment, customize sb.json with:

• Logging – Syslog servers, severity levels, console output
• Endpoints – API routes, authentication groups, URL rewrites
• Origins – Backend servers, health checks, rate limits
• BlockedHeaders – Headers to filter from requests/responses
• Webserver – Hostname, port, SSL settings

Refer to the Test project for a comprehensive configuration example.

---

Advanced Features

URL Rewriting

Transform URLs before proxying to backends:

RewriteUrls = new Dictionary<string, Dictionary<string, string>>
{
    {
        "GET", new Dictionary<string, string>
        {
            { "/v2/users/{userId}", "/v1/users/{userId}" }, // API versioning
            { "/api/data", "/legacy/data" }                 // Path migration
        }
    }
}

Authentication Context Forwarding

Pass authentication metadata to origin servers:

sb.Callbacks.AuthenticateAndAuthorize = async (ctx) =>
{
    return new AuthContext
    {
        Authentication = new AuthenticationContext
        {
            Result = AuthenticationResultEnum.Success,
            Metadata = new { UserId = "12345", Email = "user@example.com" }
        },
        Authorization = new AuthorizationContext
        {
            Result = AuthorizationResultEnum.Success,
            Metadata = new { Role = "Admin", Permissions = "read,write,delete" }
        }
    };
};

The auth context is automatically serialized and forwarded via the x-sb-auth-context header (base64-encoded).

Server-Sent Events (SSE)

Switchboard transparently proxies server-sent events:

// No special configuration needed
// SSE streams are automatically detected via Content-Type: text/event-stream

Chunked Transfer Encoding

Automatically handled for both requests and responses.

OpenAPI Documentation

Switchboard can automatically generate OpenAPI 3.0.3 documentation for your proxied routes and serve a Swagger UI:

Enable OpenAPI (JSON Configuration)

{
  "OpenApi": {
    "Enable": true,
    "EnableSwaggerUi": true,
    "DocumentPath": "/openapi.json",
    "SwaggerUiPath": "/swagger",
    "Title": "My API Gateway",
    "Version": "1.0.0",
    "Description": "API Gateway for microservices",
    "Contact": {
      "Name": "API Support",
      "Email": "support@example.com",
      "Url": "https://example.com/support"
    },
    "License": {
      "Name": "MIT",
      "Url": "https://opensource.org/licenses/MIT"
    },
    "Servers": [
      { "Url": "https://api.example.com", "Description": "Production" },
      { "Url": "https://staging-api.example.com", "Description": "Staging" }
    ],
    "SecuritySchemes": {
      "bearerAuth": {
        "Type": "http",
        "Scheme": "bearer",
        "BearerFormat": "JWT",
        "Description": "JWT Bearer token authentication"
      }
    },
    "Tags": [
      { "Name": "Users", "Description": "User management operations" },
      { "Name": "Products", "Description": "Product catalog operations" }
    ]
  },
  "Endpoints": [...]
}

Add Custom Route Documentation

Document individual routes with detailed metadata on each endpoint:

{
  "Endpoints": [
    {
      "Identifier": "user-api",
      "Name": "User API",
      "Unauthenticated": {
        "ParameterizedUrls": {
          "GET": ["/api/users/{id}"]
        }
      },
      "Authenticated": {
        "ParameterizedUrls": {
          "POST": ["/api/users"],
          "PUT": ["/api/users/{id}"]
        }
      },
      "OpenApiDocumentation": {
        "Routes": {
          "GET": {
            "/api/users/{id}": {
              "OperationId": "getUserById",
              "Summary": "Get a user by ID",
              "Description": "Retrieves detailed information about a specific user.",
              "Tags": ["Users"],
              "Parameters": [
                {
                  "Name": "id",
                  "In": "path",
                  "Required": true,
                  "SchemaType": "integer",
                  "Description": "The unique user identifier"
                }
              ],
              "Responses": {
                "200": { "Description": "User found successfully" },
                "404": { "Description": "User not found" }
              }
            }
          },
          "POST": {
            "/api/users": {
              "OperationId": "createUser",
              "Summary": "Create a new user",
              "Tags": ["Users"],
              "RequestBody": {
                "Description": "User data to create",
                "Required": true,
                "Content": {
                  "application/json": {
                    "SchemaType": "object"
                  }
                }
              },
              "Responses": {
                "201": { "Description": "User created successfully" },
                "400": { "Description": "Invalid request data" }
              }
            }
          }
        }
      },
      "OriginServers": ["backend-1"]
    }
  ]
}

Auto-Generated Documentation

Routes without explicit OpenApiDocumentation are automatically documented with:

• Summary: Generated from HTTP method and path (e.g., "GET /api/users/{id}")
• Tags: Uses the endpoint's Name or Identifier
• Path Parameters: Automatically extracted from URL patterns like {id}
• Security: Automatically added for routes in Authenticated groups

Accessing Documentation

Once enabled, access your API documentation at:

• OpenAPI JSON: http://localhost:8000/openapi.json
• Swagger UI: http://localhost:8000/swagger

---

Management API & Dashboard

Switchboard 4.0 introduces a comprehensive management system with a RESTful API and web-based dashboard for runtime configuration and monitoring.

Enabling the Management API

Add the following to your sb.json:

{
  "Database": {
    "Enable": true,
    "Type": "Sqlite",
    "Filename": "switchboard.db"
  },
  "Management": {
    "Enable": true,
    "BasePath": "/_sb/v1.0/",
    "AdminToken": "your-secure-token-here",
    "RequireAuthentication": true
  }
}

Once enabled, access the API at http://localhost:8000/_sb/v1.0/:

# List origin servers
curl -H "Authorization: Bearer your-token" http://localhost:8000/_sb/v1.0/origins

# Create a new origin
curl -X POST -H "Authorization: Bearer your-token" \
  -H "Content-Type: application/json" \
  -d '{"identifier":"api-1","hostname":"api.example.com","port":443,"ssl":true}' \
  http://localhost:8000/_sb/v1.0/origins

# Check system health
curl -H "Authorization: Bearer your-token" http://localhost:8000/_sb/v1.0/health

# Live origin server health (uptime, rolling check history, last error) for all origins
curl -H "Authorization: Bearer your-token" http://localhost:8000/_sb/v1.0/origins/health

# Live health for a single origin by GUID
curl -H "Authorization: Bearer your-token" \
  http://localhost:8000/_sb/v1.0/origins/{guid}/health

The management API also exposes endpoints that back the dashboard's overview, settings, and operations surfaces:

# Bucketed request activity for the activity chart
curl -H "Authorization: Bearer your-token" \
  "http://localhost:8000/_sb/v1.0/history/timeseries?intervalMinutes=60"

# Read the full server configuration (secrets masked) plus restart-required metadata
curl -H "Authorization: Bearer your-token" http://localhost:8000/_sb/v1.0/settings

# Update configuration (runtime-editable fields apply immediately; others need a restart)
curl -X PUT -H "Authorization: Bearer your-token" -H "Content-Type: application/json" \
  -d @settings.json http://localhost:8000/_sb/v1.0/settings

# Validate the current configuration (or a proposed one in the request body)
curl -X POST -H "Authorization: Bearer your-token" http://localhost:8000/_sb/v1.0/config/validate

# Gracefully restart the server (returns 202, then exits so a supervisor can restart it)
curl -X POST -H "Authorization: Bearer your-token" http://localhost:8000/_sb/v1.0/system/restart

See REST_API.md for complete API reference.

Running the Dashboard

The web dashboard is the primary way to operate a Switchboard server. It provides an overview with KPI cards and a request-activity chart, a request-history inspector, full CRUD for origins, endpoints, routes, users, credentials, blocked headers, and URL rewrites, live origin health monitoring (a status badge and bar histogram of recent checks per origin, plus a detail modal with uptime, consecutive counts, last error, and check timestamps), a form-based settings editor that flags which changes need a restart, a one-click server restart, an OpenAPI-driven API Explorer, and a first-run setup wizard. It ships in nine languages — English, Spanish, German, French, Portuguese, Mandarin, Cantonese, Japanese, and Farsi (Farsi with right-to-left layout) — and supports light and dark themes. Connect with an admin bearer token (sbadmin on a fresh install). See dashboard/README.md for architecture and conventions.

Development Mode

cd dashboard
npm install
npm run dev

Access the dashboard at http://localhost:5173

Production Build

cd dashboard
npm run build

The built files are in dashboard/dist/ and can be served by any static file server.

Docker

cd Docker
docker compose up -d

The dashboard will be available at http://localhost:3000

See docs/DASHBOARD-GUIDE.md for the complete user guide.

Database Configuration

Switchboard supports multiple database backends:

Database	Configuration
SQLite (default)	"Type": "Sqlite", "Filename": "switchboard.db"
MySQL	"Type": "Mysql", "Hostname": "...", "Port": 3306, ...
PostgreSQL	"Type": "Postgres", "Hostname": "...", "Port": 5432, ...
SQL Server	"Type": "SqlServer", "Hostname": "...", "Port": 1433, ...

Example MySQL configuration:

{
  "Database": {
    "Enable": true,
    "Type": "Mysql",
    "Hostname": "localhost",
    "Port": 3306,
    "DatabaseName": "switchboard",
    "Username": "switchboard",
    "Password": "your-password",
    "Ssl": false
  }
}

See docs/MIGRATION.md for migration guide and detailed configuration options.

Request History

Track and analyze requests passing through Switchboard:

{
  "RequestHistory": {
    "Enable": true,
    "CaptureRequestBody": false,
    "CaptureResponseBody": false,
    "MaxRequestBodySize": 65536,
    "MaxResponseBodySize": 65536,
    "RetentionDays": 7,
    "MaxRecords": 10000,
    "CleanupIntervalSeconds": 3600
  }
}

Query history via API:

# Get recent requests
curl -H "Authorization: Bearer your-token" \
  http://localhost:8000/_sb/v1.0/history/recent?count=100

# Get failed requests
curl -H "Authorization: Bearer your-token" \
  http://localhost:8000/_sb/v1.0/history/failed

# Get statistics
curl -H "Authorization: Bearer your-token" \
  http://localhost:8000/_sb/v1.0/history/stats

---

Observability

Switchboard instruments its request hot path with OpenTelemetry and exports metrics and traces over OTLP. The docker compose stacks bundle a complete, pre-configured backend — OpenTelemetry Collector, Prometheus, Tempo, Loki, and Grafana — so you get dashboards with zero manual setup.

What's exported

• Metrics — request rate/latency (histogram) and body sizes by endpoint; per-origin request counts, active/pending load, health (up), ejections, EWMA latency, and uptime ratio; load-balancer selections; retries and failovers; gateway rejections by reason; and build/config info. Series are labeled only by bounded values (endpoint, origin, method, status code, reason) — never by raw path or client IP.
• Traces — one span per proxied request (proxy {endpoint}) with the endpoint, origin, method, and status attributes; the W3C traceparent header is propagated to the origin so it can continue the trace.
• Logs — collected from Switchboard's log files by the Collector's filelog receiver and shipped to Loki.

Enabling it

Telemetry is off by default in a standalone build and on in the bundled Docker stacks. Turn it on by setting the Telemetry block in sb.json (or from the dashboard under Settings → Telemetry & Observability, or the management API), pointing OTLP at your collector:

"Telemetry": {
  "Enable": true,
  "ServiceName": "switchboard",
  "Metrics": { "Enable": true, "ExportIntervalMs": 15000 },
  "Traces": { "Enable": true, "SamplingRatio": 1.0, "PropagateToOrigin": true },
  "Logs": { "Enable": true, "MinimumSeverity": 1 },
  "Otlp": { "Endpoint": "http://otel-collector:4317", "Protocol": "grpc", "TimeoutMs": 10000, "Headers": null }
}

Most fields require a restart to rewire the exporters; Traces.PropagateToOrigin applies live. The OTLP Headers value is treated as a secret and masked by the management API. Switchboard exposes no metrics port of its own — Prometheus scrapes the Collector.

Accessing Grafana

After docker compose up -d, give the containers a few seconds, then:

1. Open http://localhost:3001. You are not prompted to log in — the stack enables anonymous access with the Admin role. (If you later disable anonymous access, Grafana's default login is admin / admin.)
2. The Prometheus, Tempo, and Loki data sources are already wired up — nothing to configure.
3. Open Dashboards → Switchboard Overview (it is provisioned into the top-level list).
4. Panels start empty. They fill once traffic flows through the proxy and the first export/scrape interval elapses (~15 s). Generate some traffic — e.g. curl http://localhost:8000/ a few times, or run the LoadGenerator project — then refresh.
5. For traces and logs, use Explore (compass icon): pick Tempo to find spans (service switchboard) or Loki to query logs ({service_name="switchboard"}); you can pivot from a trace to its logs and back.

The dashboard's Observability view (under Operate) shows live telemetry status — enabled signals, OTLP endpoint, sampling ratio — and links straight out to Grafana and Prometheus.

Ports (host): Grafana 3001, Prometheus 9090, OTLP 4317/4318. See the Docker Compose services table for every service's URL and credentials.

---

Support

Getting Help

• Documentation: Check the README and code examples in the Test project
• GitHub Issues: Report bugs or request features at GitHub Issues
• GitHub Discussions: Ask questions and share ideas at GitHub Discussions

We welcome your feedback and contributions!

---

Contributing

We'd love your help improving Switchboard! Contributions are welcome in many forms:

• Code: New features, bug fixes, performance optimizations
• Documentation: Improve guides, add examples, fix typos
• Testing: Write tests, report bugs, validate fixes
• Ideas: Suggest features, share use cases, provide feedback

How to Contribute:

1. Fork the repository
2. Create a feature branch (git checkout -b feature/amazing-feature)
3. Commit your changes (git commit -m 'Add amazing feature')
4. Push to your branch (git push origin feature/amazing-feature)
5. Open a Pull Request

Please ensure your code follows existing conventions and includes tests where applicable.

---

License

Switchboard is licensed under the MIT License.

See the LICENSE.md file for details.

TL;DR: You can use, modify, and distribute Switchboard freely, including for commercial purposes. No warranty is provided.
