RAGify

Build production‑ready RAG applications in .NET — retrieval and generation — with one clean, fluent API.

Ingest → Chunk → Embed → Store → Retrieve → Rerank → Generate — every stage swappable, every provider pluggable.

Install · Quick Start · How It Works · Generation · Providers · Configuration · Architecture · Contributing

</div>

---

📦 Install

dotnet add package RAGify

That is the only package. RAGify ships as one NuGet package and one assembly — ingestion, chunking, embeddings, vector stores, retrieval, reranking, generation, and DI included.

Requirements: .NET 10.0+ · Windows, Linux, or macOS · (optional) Ollama for local models · ONNX Runtime is included automatically.

<details> <summary><b>Upgrading from 2.x?</b></summary>

RAGify used to ship as eight packages. As of 3.0.0 the seven secondary packages — RAGify.Abstractions, RAGify.Core, RAGify.Ingestion, RAGify.Chunking, RAGify.Embeddings, RAGify.VectorStores, RAGify.Retrieval — are discontinued and folded into RAGify.

Migration is one line of XML. Delete every RAGify.* <PackageReference> and keep a single one:

<PackageReference Include="RAGify" Version="3.0.0" />

Your C# does not change. The namespaces are untouched — RAGify.Abstractions, RAGify.Chunking, RAGify.Embeddings and friends all still exist inside the single assembly, so every existing using statement, type, and method signature compiles exactly as before.

</details>

---

⚡ Quick Start

Retrieve and generate a grounded answer:

using RAGify;
using RAGify.Core;

var rag = new RagifyConfig()
    .WithChunking(ChunkingStrategyType.SentenceAware)
    .WithOpenAIEmbeddings("your-openai-key", "text-embedding-3-small")
    .WithInMemoryVectorStore()
    .WithOpenAIChat("your-openai-key", model: "gpt-4o-mini")   // 👈 the "G" in RAG
    .Build();

// Ingest knowledge
await rag.IngestAsync(Document.FromText(
    "RAGify is a modular .NET framework for Retrieval-Augmented Generation...",
    documentId: "doc-1", source: "intro"));

// Ask a question → get a grounded, cited answer
var result = await rag.AnswerAsync("What is RAGify?");

Console.WriteLine(result.Answer);                 // natural-language answer
Console.WriteLine($"Model: {result.Generation?.Model}");
foreach (var ctx in result.Context)              // the sources it was grounded in
    Console.WriteLine($"  [{ctx.Similarity:F3}] {ctx.Source}");

<details> <summary><b>Fully local — no API keys (Ollama)</b></summary>

var rag = new RagifyConfig()
    .WithChunking(ChunkingStrategyType.SentenceAware)
    .WithOllamaEmbeddings("all-minilm")     // local embeddings
    .WithInMemoryVectorStore()
    .WithOllamaChat("llama3.2")             // local generation
    .Build();

</details>

<details> <summary><b>Retrieval only (no LLM)</b></summary>

var result = await rag.QueryAsync("What is the main topic?");
foreach (var ctx in result.Context)
    Console.WriteLine($"[{ctx.Similarity:F3}] {ctx.Chunk.Text}");

</details>

---

🔄 How It Works

flowchart LR
    A[📄 Documents<br/>PDF · DOCX · XLSX · HTML<br/>MD · CSV · JSON · URL] --> B[✂️ Chunking]
    B --> C[🔢 Embeddings<br/>+ cache + retry]
    C --> D[(💾 Vector Store)]
    Q[❓ Query] --> E[🔍 Retrieve]
    D --> E
    E --> F[🥇 Rerank]
    F --> G[🤖 Generate<br/>grounded + cited]
    G --> R[💬 Answer]

RAGify turns that full pipeline into a few lines of fluent C#. It is the complete loop — not just retrieval — so you go from raw documents to a grounded, cited answer without gluing five libraries together.

• Provider‑agnostic — 8 embedding providers, 5 vector stores, 4 LLM providers, 2 rerankers. Swap any of them by changing one line.
• The "G" in RAG, built in — grounded, cited answers via OpenAI, Azure OpenAI, Anthropic (Claude), or local Ollama. Streaming included.
• Clean architecture — small, focused interfaces (IEmbeddingProvider, IVectorStore, IReranker, ILlmProvider, …) you can implement yourself.
• Production‑minded — embedding cache, retry/backoff, batching, metadata filtering, deduplication, dynamic Top‑K, and first‑class logging.
• DI‑ready — services.AddRagify(...) and you are wired into ASP.NET Core.

Stage	What you get
Ingestion	PDF, Word (.docx), Excel (.xlsx), HTML, Markdown, CSV/TSV, JSON/JSONL, plain text, and web pages by URL. Files, streams, or raw text.
Chunking	Fixed‑size, Sentence‑aware, Sliding‑window, Recursive, Markdown‑aware, and Token‑aware strategies — all configurable and extensible.
Embeddings	8 providers: OpenAI, Azure OpenAI, Ollama, ONNX, Hugging Face, Cohere, VoyageAI, Google Gemini. Async + batch, auto‑normalized.
Vector Stores	5 stores: In‑Memory, Qdrant, PgVector, Pinecone, Weaviate. Metadata filtering, Top‑K, thresholds, batch ops.
Retrieval	Query‑type detection, dynamic Top‑K, multi‑signal deduplication, low‑value filtering, similarity thresholds.
Reranking	Cohere Rerank API + a dependency‑free local BM25 lexical reranker. Pluggable via IReranker.
Generation	Grounded, cited answers via OpenAI, Azure OpenAI, Anthropic (Claude), or Ollama — with token‑by‑token streaming.
Performance	Embedding cache, HTTP retry/backoff (429/5xx + Retry-After), automatic sub‑batching.
Hosting	AddRagify(...) for Microsoft.Extensions.DependencyInjection, plus full ILogger support.

---

🤖 Answer Generation

Configure any ILlmProvider, then call AnswerAsync for a grounded answer or StreamAnswerAsync for streaming.

// Pick a chat provider
.WithOpenAIChat("key", model: "gpt-4o-mini")
.WithAzureOpenAIChat("key", deploymentName: "gpt-4o", resourceName: "your-resource")
.WithAnthropicChat("key", model: "claude-opus-4-8")   // Claude
.WithOllamaChat("llama3.2")                            // local
.WithLlm(myCustomLlmProvider)                          // your own ILlmProvider

Stream tokens as they are generated:

await foreach (var token in rag.StreamAnswerAsync("Explain RAGify in detail"))
    Console.Write(token);

Customize the system prompt, temperature, and citations:

var result = await rag.AnswerAsync("What is RAGify?", new QueryOptions
{
    Generation = new GenerationOptions
    {
        SystemPrompt   = "You are a concise technical assistant. Cite sources as [n].",
        Temperature    = 0.1,
        MaxTokens      = 500,
        IncludeCitations = true
        // PromptTemplate = "Context:\n{context}\n\nQ: {query}"   // or fully override the prompt
    }
});

QueryResult exposes Answer, Generation (model + token usage), and the retrieved Context, so you always know exactly what grounded the answer.

---

🔌 Providers

Embedding providers (8)

Provider	Example models	Best for
OpenAI	text-embedding-3-small/large, ada-002	High accuracy, production
Azure OpenAI	All OpenAI models via Azure	Enterprise / compliance
Ollama	nomic-embed-text, all-minilm	Local, privacy‑sensitive
ONNX	Any ONNX SentenceTransformer	Offline, cost‑free inference
Hugging Face	1000+ Inference API models	Research / experimentation
Cohere	embed-english-v3.0, multilingual	Multilingual apps
VoyageAI	voyage-large-2, voyage-code-2	Code & specialized tasks
Google Gemini	text-embedding-004	Google Cloud integrations

<details> <summary><b>Configuration snippets for each embedding provider</b></summary>

.WithOpenAIEmbeddings(apiKey: "key", model: "text-embedding-3-small", dimension: 1536)
.WithAzureOpenAIEmbeddings(apiKey: "key", deploymentName: "text-embedding-ada-002",
                           resourceName: "your-resource", apiVersion: "2024-02-15-preview")
.WithOllamaEmbeddings(model: "all-minilm", baseUrl: "http://localhost:11434")
.WithOnnxEmbeddings(modelPath: "model.onnx", dimension: 384)
.WithHuggingFaceEmbeddings(apiKey: "hf-token", modelId: "sentence-transformers/all-MiniLM-L6-v2")
.WithCohereEmbeddings(apiKey: "key", model: "embed-english-v3.0", inputType: "search_document")
.WithVoyageAIEmbeddings(apiKey: "key", model: "voyage-large-2")
.WithGoogleGeminiEmbeddings(apiKey: "key", model: "text-embedding-004")

</details>

Vector stores (5)

Store	Type	Best for
In‑Memory	Local	Dev, testing, < 100K vectors
Qdrant	Open‑source	High‑performance, self‑hosted, scales to billions
PgVector	PostgreSQL ext.	Existing Postgres infra, small–medium datasets
Pinecone	Managed cloud	Fully managed, serverless, auto‑scaling
Weaviate	Open‑source/cloud	Hybrid search, flexible schema

<details> <summary><b>Configuration snippets for each vector store</b></summary>

.WithInMemoryVectorStore()
.WithQdrantVectorStore(host: "localhost", port: 6333, collectionName: "ragify", vectorSize: 1536)
.WithPgVectorStore(connectionString: "Host=localhost;Database=ragify;Username=postgres;Password=pwd",
                   tableName: "ragify_vectors", vectorSize: 1536)
.WithPineconeVectorStore(apiKey: "key", indexName: "ragify-index", environment: "us-east-1-aws")
.WithWeaviateVectorStore(baseUrl: "http://localhost:8080", className: "RAGifyVector")

You can also pass any custom IVectorStore via .WithVectorStore(store). See Configuration for the full PgVectorStoreOptions (custom SQL, HNSW indexes, etc.).

</details>

LLM providers (4) and rerankers (2)

LLM (generation)	Reranker
OpenAI · Azure OpenAI · Anthropic (Claude) · Ollama	Cohere Rerank · Local BM25 lexical

---

🧩 Pipeline Stages

Chunking

Strategy	ChunkingStrategyType	Description
Fixed Size	FixedSize	Character windows with configurable overlap
Sentence‑Aware	SentenceAware	Respects sentence boundaries (keeps punctuation)
Sliding Window	SlidingWindow	Overlapping windows for context preservation
Recursive	Recursive	Splits by paragraph → line → sentence → word to fit the size limit
Markdown	Markdown	Splits on headings, keeps code fences intact
Token‑Aware	TokenAware	Sizes chunks by estimated tokens (pluggable tokenizer)

.WithChunking(ChunkingStrategyType.Recursive, new ChunkingOptions
{
    ChunkSize = 1000,
    OverlapSize = 200,
    RespectSentenceBoundaries = true
})

Document ingestion

WithDefaultExtractors() handles PDF, Word, Excel, HTML, Markdown, CSV/TSV, JSON/JSONL, and plain text. Web pages are ingested by URL.

var ingestion = DocumentIngestionService.CreateDefault();

var fromFile     = await ingestion.IngestFromFileAsync("report.pdf");
var fromMarkdown = await ingestion.IngestFromFileAsync("README.md");
var fromCsv      = await ingestion.IngestFromFileAsync("data.csv");
var fromWeb      = await ingestion.IngestFromUrlAsync("https://example.com/article");

await rag.IngestAsync(fromWeb);

// Batch ingestion
await rag.IngestBatchAsync(documents);

Reranking

Add a second‑stage reranker to refine result ordering after vector search:

.WithCohereReranker("your-cohere-key")   // Cohere Rerank API
.WithLexicalReranker()                    // dependency-free local BM25 — great offline
.WithReranker(myCustomReranker)           // any IReranker

Embedding cache and resilience

Cut API cost/latency and harden network calls:

using RAGify.Embeddings;

var rag = new RagifyConfig()
    .WithChunking(ChunkingStrategyType.SentenceAware)
    .WithOpenAIEmbeddings("key", "text-embedding-3-small",
        httpClient: ResilientHttpClientFactory.Create(maxRetries: 3)) // retry 429/5xx + Retry-After
    .WithInMemoryEmbeddingCache(maxEntries: 100_000)                  // skip re-embedding duplicates
    .WithInMemoryVectorStore()
    .Build();

Need provider‑side batch limits respected? Wrap any provider with BatchingEmbeddingProvider.

---

🏗️ Dependency Injection

using Microsoft.Extensions.DependencyInjection;

services.AddRagify(cfg => cfg
    .WithChunking(ChunkingStrategyType.SentenceAware)
    .WithOpenAIEmbeddings("key", "text-embedding-3-small")
    .WithInMemoryVectorStore()
    .WithOpenAIChat("key"));

// Inject anywhere
public class SearchService(IRagify rag)
{
    public Task<QueryResult> Ask(string q) => rag.AnswerAsync(q);
}

---

⚙️ Configuration

<details> <summary><b>Chunking options</b></summary>

new ChunkingOptions
{
    ChunkSize = 1000,                 // max chunk size in characters (or tokens for TokenAware)
    OverlapSize = 200,                // overlap between chunks
    RespectSentenceBoundaries = true,
    RespectTokenBoundaries = false,
    MaxSentencesPerChunk = 5
}

Recommendations: general text 1000–1500 / 200–300; code 500–800 / 100–150. Use SentenceAware/Recursive for prose, Markdown for docs, TokenAware to respect model token limits.

</details>

<details> <summary><b>Retrieval options</b></summary>

new RetrievalOptions
{
    TopK = 5,                    // 0 = dynamic Top-K based on question type
    SimilarityThreshold = 0.7,   // 0.0–1.0  (0.5–0.7 is a good default)
    EnableDynamicTopK = true,
    EnableDeduplication = true,
    Filter = new MetadataFilter
    {
        Filters = new() { ["Category"] = "Technical", ["Year"] = 2024 }
    }
}

</details>

<details> <summary><b>PgVector — custom SQL, HNSW indexes & more</b></summary>

PgVectorStoreOptions lets you override every SQL statement (SearchQuery, UpsertQuery, CreateIndexQuery, FilterConditionTemplate, …) using placeholders {tableName}, {vectorSize}, {whereClause}. Example HNSW index:

var options = new PgVectorStoreOptions
{
    CreateIndexQuery = @"CREATE INDEX IF NOT EXISTS {tableName}_embedding_idx
        ON {tableName} USING hnsw (embedding vector_cosine_ops) WITH (m = 16, ef_construction = 64)"
};
.WithPgVectorStore("connection-string", "ragify_vectors", 1536, options)

</details>

<details> <summary><b>Logging</b></summary>

RAGify integrates with Microsoft.Extensions.Logging. Pass a logger to surface ingestion, chunking, embedding, storage, retrieval, and generation activity:

var loggerFactory = LoggerFactory.Create(b => b.AddConsole().SetMinimumLevel(LogLevel.Information));
var rag = new RagifyConfig()
    /* ... */
    .WithLogger(loggerFactory.CreateLogger<Ragify>())
    .Build();

Use Information in production, Debug while diagnosing. Logging is optional.

</details>

---

💡 Examples

<details> <summary><b>Ingest files from a folder & query with metadata filtering</b></summary>

var ingestion = DocumentIngestionService.CreateDefault();
var docs = new List<IDocument>();
foreach (var path in Directory.GetFiles("documents/", "*.pdf"))
    docs.Add(await ingestion.IngestFromFileAsync(path,
        metadata: new() { ["Category"] = "Technical" }));

await rag.IngestBatchAsync(docs);

var result = await rag.AnswerAsync("What is machine learning?", new QueryOptions
{
    Retrieval = new RetrievalOptions
    {
        TopK = 10,
        SimilarityThreshold = 0.7,
        Filter = new MetadataFilter { Filters = new() { ["Category"] = "Technical" } }
    }
});

</details>

<details> <summary><b>Self-hosted, cost-efficient stack (Qdrant + Cohere rerank + Claude)</b></summary>

var rag = new RagifyConfig()
    .WithChunking(ChunkingStrategyType.Recursive)
    .WithOpenAIEmbeddings("openai-key", "text-embedding-3-small")
    .WithQdrantVectorStore(host: "localhost", port: 6333, collectionName: "kb", vectorSize: 1536)
    .WithCohereReranker("cohere-key")
    .WithAnthropicChat("anthropic-key", model: "claude-opus-4-8")
    .WithInMemoryEmbeddingCache()
    .Build();

</details>

<details> <summary><b>Console test app</b></summary>

ollama pull all-minilm:latest    # if using Ollama
dotnet run --project test/RAGify.ConsoleTest

Interactive harness for ingesting files/text, browsing chunks, querying, and tuning Top‑K / thresholds at runtime, with live logging.

</details>

---

🏛️ Architecture

RAGify follows clean architecture inside a single project. Each layer is a folder — and a namespace — rather than a separate package:

RAGify.sln
├── src/
│   └── RAGify/                 # The one package & assembly — everything lives here
│       ├── Abstractions/       # Interfaces & contracts (no dependencies)
│       ├── Core/               # Domain models & utilities (VectorMath, TextCleanup)
│       ├── Ingestion/          # Document extractors (PDF/Word/Excel/HTML/MD/CSV/JSON/Web)
│       ├── Chunking/           # Chunking strategies
│       ├── Embeddings/         # 8 embedding providers + cache/resilience/batching
│       ├── VectorStores/       # 5 vector stores
│       ├── Retrieval/          # Retrieval engine (+ reranking hook)
│       ├── Generation/         # LLM chat providers + grounded prompt builder
│       ├── Reranking/          # Cohere Rerank + local BM25 lexical reranker
│       └── Ragify.cs           # Orchestrator, RagifyConfig builder, DI extensions
└── test/
    ├── RAGify.ConsoleTest/     # Interactive console harness
    └── RAGify.Tests/           # Unit & integration test suite

Namespaces mirror the folders — RAGify.Abstractions, RAGify.Core, RAGify.Chunking, RAGify.Embeddings, RAGify.Ingestion, RAGify.Retrieval, RAGify.VectorStores, RAGify.Generation, RAGify.Reranking — so the layering stays explicit in code even though it all compiles into one assembly.

Dependency flow: Abstractions ← Core ← {Ingestion, Chunking, Embeddings, VectorStores, Retrieval} ← RAGify.

Extending RAGify

Every stage is an interface — implement and plug in your own:

Interface	Implement to add…
IDocumentExtractor	a new file format
IChunkingStrategy	a custom chunking algorithm
IEmbeddingProvider	a new embedding backend
IVectorStore	a new vector database
IReranker	a custom reranking model
ILlmProvider	a new chat/LLM backend
IEmbeddingCache	a distributed cache (Redis, etc.)

var rag = new RagifyConfig()
    .WithEmbeddings(new MyEmbeddingProvider())
    .WithVectorStore(new MyVectorStore())
    .WithReranker(new MyReranker())
    .WithLlm(new MyLlmProvider())
    .Build();

---

🎯 Best Practices

• Chunking: balance size vs. relevance; use overlap to preserve context; match your embedding model's optimal input length.
• Embeddings: enable the cache for repeated content; choose local (Ollama/ONNX) vs. cloud per privacy/cost; use a resilient HttpClient in production.
• Vector stores: In‑Memory for dev; PgVector/Qdrant for self‑hosted; Pinecone for fully managed. Index properly (HNSW for large datasets) and use metadata filters to narrow scope.
• Retrieval & generation: start with Top‑K 5–10 and threshold 0.5–0.7; add a reranker for precision; keep Temperature low (0.0–0.2) for factual answers and rely on citations.
• Security: keep API keys in environment variables/secret stores; use HTTPS and auth for remote stores.

---

🐛 Troubleshooting

Issue	Fix
No extractor found for file	Use WithDefaultExtractors() or add a custom IDocumentExtractor.
Ollama connection errors	Ensure Ollama is running and the model is pulled (ollama pull <model>); check the base URL.
Low similarity scores	Lower the threshold (0.5–0.7), increase overlap, verify the embedding provider, ensure vectors are normalized.
AnswerAsync throws InvalidOperationException	Configure an LLM with WithOpenAIChat()/WithAnthropicChat()/WithOllamaChat()/WithLlm().
PgVector query errors	Install the extension (CREATE EXTENSION vector;) and match vector dimensions to your model.
Memory issues on large datasets	Use a persistent vector store, smaller batches, and an HNSW index.

---

🗺️ Roadmap

• Hybrid (keyword + vector) search
• Conversation / chat memory
• Built‑in evaluation metrics (precision / recall / nDCG / faithfulness)
• More providers (Mistral, Jina, Bedrock) and stores (Redis, Milvus, Azure AI Search)
• OpenTelemetry metrics & tracing

Have an idea? Open an issue or a PR.

---

🤝 Contributing

Contributions are welcome.

1. Fork & create a feature branch: git checkout -b feature/amazing-feature
2. Follow the existing style (file‑scoped namespaces, XML docs, one class per file, Models/ folders)
3. Add tests for new behavior
4. Update the README/docs
5. Open a PR with a clear description

---

📄 License

Licensed under the MIT License — see LICENSE.

Acknowledgments — built with .NET, inspired by modern RAG architectures, and thankful to every embedding/LLM provider team for their excellent APIs.

💖 Support

If RAGify saves you time, consider supporting development:

• 💳 PayPal — paypal.me/FarhanLodi
• 📱 UPI (India) — farhanlodi5@oksbi
• 🏦 Bank transfer (USD) — details below

<details> <summary><b>USD bank transfer details (Wise)</b></summary>

USD account details for Farhan Lodi on Wise. Sending from a bank in the US? Use these details for a domestic transfer. Sending from anywhere else? Make an international SWIFT transfer.

Field	Value
Name	Farhan Lodi
Account type	Deposit
Routing number (wire and ACH)	084009519
Account number	420927686563885
SWIFT/BIC	TRWIUS35XXX
Bank address	Wise US Inc, 108 W 13th St, Wilmington, DE, 19801, United States

Use the routing and account numbers when sending from the US, and the SWIFT/BIC when sending from outside the US.

</details>

📧 Need more details, a different payment method, or have a question? Email farhanlodi31@gmail.com.

<div align="center">

---

Made with ❤️ for the .NET community — if this helped you, please ⭐ the repo!

</div>
