HexaGen.CppAst 1.0.8

HexaGen.CppAst

<img align="right" width="160px" height="160px" src="https://raw.githubusercontent.com/HexaEngine/HexaGen.CppAst/main/icon.png">

HexaGen.CppAst is a complete rewrite and modernization of CppAst.NET, providing a powerful C/C++ parser for header files with full access to the AST, comments, and macros for .NET 9+.

What Makes HexaGen.CppAst Different

Originally started as a fork of CppAst.NET, HexaGen.CppAst is now a complete ground-up rewrite that addresses fundamental architectural limitations of the original library:

?? Full Low-Level API Access

• Direct CXCursor API Access: Unlike the original CppAst, HexaGen.CppAst exposes the underlying libclang CXCursor API through the ICppElement.Cursor property
• Advanced Scenarios: Enables sophisticated parsing scenarios that require direct interaction with libclang's cursor system
• No Hidden Abstractions: Every AST element provides direct access to its underlying Clang representation for maximum flexibility

??? Modern, Extensible Architecture

• Visitor Pattern System: Clean, extensible architecture using the visitor pattern (CursorVisitor<TResult>)
• Pluggable Parsers: Register custom visitors for specific cursor types through CursorVisitorRegistry
• Container-Based Processing: Hierarchical context system (CppContainerContext) for proper scope management
• Type System Redesign: Comprehensive type resolution with TypedefResolver and improved canonical type handling

?? Performance & Quality Improvements

• Despagettification: Complete restructuring eliminates callback hell and deeply nested code
• Efficient Memory Management: Custom allocators and improved string handling (CString, BumpAllocator)
• Better Diagnostics: Enhanced source location tracking and error reporting
• AOT-Ready: Full support for Native AOT compilation with trim and AOT analyzers enabled

?? Enhanced Features

• Comprehensive Comment Parsing: Full support for all libclang comment types (block, inline, param, etc.)
• Improved Attribute Handling: Better support for __attribute__, [[]], and __declspec attributes
• Template Support: Enhanced handling of template classes and specializations
• Flexible Tokenization: Advanced tokenizer with support for complex macro expansions

Purpose

HexaGen.CppAst serves as a robust foundation for P/Invoke/Interop code generation and C++ code analysis tools

Key Features

• Targeting: net9.0 with full AOT compatibility
• Clang Version: Uses ClangSharp 20.1.2 / libclang 20.1.2
• Parsing Modes:
  • Parse in-memory C/C++ text
  • Parse C/C++ files from disk
• Comprehensive AST:
  • Simple, intuitive AST model
  • Full type system representation
  • Access to attributes (_declspec(...), __attribute__((...)), [[...]])
  • Attached comments with full structure
  • Expression trees for initializers (e.g., const int x = (1 + 2) << 1)
• Macro Support: Access to macro definitions and tokens via CppParserOptions.ParseMacros
• Direct CXCursor Access: Every ICppElement exposes its underlying CXCursor for advanced scenarios

Architecture Overview

// Core interfaces
ICppElement          // Base interface exposing CXCursor
ICppDeclaration      // Declarations with comments
ICppContainer        // Containers with children

// Visitor system
CursorVisitor<TResult>              // Base visitor class
CursorVisitorRegistry<TVisitor, TResult>  // Visitor registration
DeclContainerVisitorRegistry        // Declaration container visitors

// Context management
CppModelContext      // Parsing context
CppContainerContext  // Container scope context

Quick Start

Setup

After installing the NuGet package, modify your .csproj to select a Platform RID:

<PropertyGroup>

  <RuntimeIdentifier Condition="'$(RuntimeIdentifier)' == '' AND '$(PackAsTool)' != 'true'">$(NETCoreSdkRuntimeIdentifier)</RuntimeIdentifier>
</PropertyGroup>

Basic Usage

using HexaGen.CppAst;

// Parse C++ code
var compilation = CppParser.Parse(@"
enum MyEnum { MyEnum_0, MyEnum_1 };
void function0(int a, int b);
struct MyStruct { int field0; int field1;};
typedef MyStruct* MyStructPtr;
");

// Print diagnostics
foreach (var message in compilation.Diagnostics.Messages)
    Console.WriteLine(message);

// Access AST elements
foreach (var cppEnum in compilation.Enums)
    Console.WriteLine(cppEnum);

foreach (var cppFunction in compilation.Functions)
    Console.WriteLine(cppFunction);

foreach (var cppClass in compilation.Classes)
    Console.WriteLine(cppClass);

foreach (var cppTypedef in compilation.Typedefs)
    Console.WriteLine(cppTypedef);

Output:

enum MyEnum {...}
void function0(int a, int b)
struct MyStruct { ... }
typedef MyStruct* MyStructPtr

Advanced: Direct CXCursor Access

// Every ICppElement exposes the underlying CXCursor
var function = compilation.Functions[0];
var cursor = function.Cursor;

// Access low-level libclang information
var linkage = cursor.Linkage;
var availability = cursor.Availability;
var semanticParent = cursor.SemanticParent;

// Use CXCursor for advanced scenarios
if (cursor.Kind == CXCursorKind.CXCursor_FunctionDecl)
{
    // Perform custom cursor operations
    // Visit children, access tokens, etc.
}

Extending the Parser

// Create a custom visitor
public class MyCustomVisitor : CursorVisitor<CppElement>
{
    public override IEnumerable<CXCursorKind> Kinds =>
        new[] { CXCursorKind.CXCursor_ClassDecl };

    protected override unsafe CppElement VisitCore(CXCursor cursor, CXCursor parent)
    {
        // Custom parsing logic
        // Access Context, Builder, Container, etc.
        return new MyCustomElement(cursor);
    }
}

// Register the visitor
var registry = new CursorVisitorRegistry<CursorVisitor<CppElement>, CppElement>();
registry.Register<MyCustomVisitor>();

Documentation

For detailed documentation, see the user guide in the doc/ folder.

Migration from CppAst.NET

While HexaGen.CppAst maintains API compatibility with common use cases, the underlying architecture is completely new. Key differences:

1. Direct Cursor Access: All elements expose ICppElement.Cursor for low-level operations
2. Visitor Pattern: Extension points use the visitor pattern instead of callbacks
3. Improved Type System: Better canonical type resolution and typedef handling
4. Modern .NET: Targets .NET 9 with full AOT support (use CppAst 0.14.0 for netstandard2.0)

Binaries

Available as a NuGet package:

Known Limitations

Inherited from libclang:

• Attributes are not fully exposed in all contexts (e.g., function parameters, typedefs)
• Generic instance types have limited exposure (e.g., as parameters or base types)

License

This software is released under the MIT License.

Credits

• Original CppAst.NET by Alexandre Mutel (xoofx)
• ClangSharp: .NET managed wrapper around Clang/libclang

Related Projects

• cppast: C++ library with similar goals
• HexaGen: Code generator using HexaGen.CppAst

Author

Juna Meinhold

Note: While originally inspired by CppAst.NET, HexaGen.CppAst represents a complete architectural reimagining with modern .NET practices, better extensibility, and direct access to the underlying libclang cursor API for advanced parsing scenarios.
